Gniazdo procesora: Socket 1851
Obsługiwane typy procesorów: Intel Core Ultra Processors (series 2)
Format płyty: ATX
Chipset płyty głównej: Intel® Z890
Ilość złącz pamięci DDR5: 4
Maksymalna wielkość pamięci: 256 GB
Tryb pracy pamięci RAM: Dual Channel
Uwagi do pamięci RAM: Max. overclocking frequency:, - 1DPC 1R Max speed up to 9200+ MT/s, - 1DPC 2R Max speed up to 7200+ MT/s, - 2DPC 1R Max speed up to 6400+ MT/s, - 2DPC 2R Max speed up to 5600+ MT/s, Supports Intel® POR Speed and JEDEC Speed, Supports Memory Overclocking and Intel® XMP 3.0, Supports Non-ECC, Un-buffered memory, Supports CUDIMM
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 5x M.2 + RAID 0,1,5,10
Uwagi do kontrolera SATA: - M.2_1 Source (From CPU) supports up to PCIe 5.0 x4,, supports 2280/2260 devices, - M.2_2 Source (From CPU) supports up to PCIe 4.0 x4,, supports 2280/2260 devices, - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 ,, supports 2280/2260 devices, - M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4,, supports 22110/2280 devices, - M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode,, supports 22110/2280/2260 devices, Please refer to the manual for M.2 SSD heatsink restrictions.
Gniazda karty graficznej: HDMI, 2x Thunderbolt
Uwagi do karty graficznej: Support HDMI 2.1 with FRL port, maximum resolution of 8K 60Hz, Thunderbolt™ 4 ports, supporting DisplayPort 2.1 with UHBR20 over, USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz, Graphics specifications may vary depending on the CPU installed
Zintegrowana karta dźwiękowa: Realtek® ALC1220P Codec 7.1-Channel High Definition Audio
Gniazda karty dźwiękowej: Wewnętrzne gniazdo audio przedniego panelu, 2x Audio Jack, Wyjście optyczne S/PDIF
Złącza PCI Express x16: 2
Złącza PCI Express x1: 1
Uwagi do złącz PCI: - PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), - PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset), - PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset), PCI_E1 support manual BIOS adjustment to X8+X8 / X8+X4+X4
Port LAN: 1x 5 Gigabit LAN Intel® Killer™ E5000B
Maksymalna ilość portów USB 2.0: 5
Maksymalna ilość portów USB 3.x: 12
Maksymalna ilość portów USB 4.0: 2
Porty USB na panelu tylnym: 1x USB 2.0 + 4x USB 3.0 + 4x USB 3.1 + 1x USB 3.1 Type-C + 2x Thunderbolt 4/USB4
Gniazda USB na płycie głównej: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.2 Type-C
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Intel® Killer™ BE1750x Wi-Fi 7, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax/ be, Supports Bluetooth® 5.4**, MLO, 4KQAM, 6GHz band support may depend on every country's regulations and Wi-Fi 7, will be ready in Windows 11 version 24H2., The Bluetooth version may be updated, please refer to the Wi-Fi chipset, vendor's website for details. Bluetooth 5.4 will be ready in, Windows 11 version 24H2.
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU Fan, Combo Fan (Pump_Sys Fan), 6x System Fan, EZ Conn-header (JAF_2), 2x Front Panel, Chassis Intrusion (JCI), Thunderbolt 5 card connector(JTBT5, support RTD3), Thermal Sensor connectors, 3x Addressable V2 RGB LED connector, RGB LED connector, TPM pin header
Gniazdo zasilania: ATX (24-pin) + 2x ATX12V (8-pin) + PCIe (8-pin)
Wymiary [S x W] (mm): 243,84 x 304,8
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Windows® 11 64-bit
Parametry:
Zawiera baterię / akumulator:
Tak
Wymiary [S x W] (mm):
243,84 x 304,8
Maksymalna wielkość pamięci:
256 GB
Port LAN:
1x 5 Gigabit LAN Intel® Killer™ E5000B
Port Wi-Fi:
IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth:
Bluetooth V5.4
Chipset płyty głównej:
Intel® Z890
Gniazdo procesora:
Socket 1851
Obsługiwane typy procesorów:
Intel Core Ultra Processors (series 2)
Tryb pracy pamięci RAM:
Dual Channel
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 5x M.2 + RAID 0,1,5,10
Gniazda karty graficznej:
2x Thunderbolt, HDMI
Zintegrowana karta dźwiękowa:
Realtek® ALC1220P Codec 7.1-Channel High Definition Audio
Gniazda karty dźwiękowej:
2x Audio Jack, Wewnętrzne gniazdo audio przedniego panelu, Wyjście optyczne S/PDIF
Złącza PCI Express x16:
2
Maksymalna ilość portów USB 2.0:
5
Maksymalna ilość portów USB 3.x:
12
Porty USB na panelu tylnym:
1x USB 2.0 + 4x USB 3.0 + 4x USB 3.1 + 1x USB 3.1 Type-C + 2x Thunderbolt 4/USB4
Gniazda USB na płycie głównej:
4x USB 2.0 + 2x USB 3.0 + 1x USB 3.2 Type-C
Port szeregowy (COM):
Brak
Inne porty i gniazda:
2x Front Panel, 3x Addressable V2 RGB LED connector, 6x System Fan, Chassis Intrusion (JCI), Combo Fan (Pump_Sys Fan), CPU Fan, EZ Conn-header (JAF_2), RGB LED connector, Thermal Sensor connectors, Thunderbolt 5 card connector(JTBT5, support RTD3), TPM pin header
Gniazdo zasilania:
ATX (24-pin) + 2x ATX12V (8-pin) + PCIe (8-pin)
Uwagi do pamięci RAM:
- 1DPC 1R Max speed up to 9200+ MT/s, - 1DPC 2R Max speed up to 7200+ MT/s, - 2DPC 1R Max speed up to 6400+ MT/s, - 2DPC 2R Max speed up to 5600+ MT/s, Max. overclocking frequency, Supports CUDIMM, Supports Intel POR Speed and JEDEC Speed, Supports Memory Overclocking and Intel® XMP 3.0, Supports non-ECC, un-buffered memory
Uwagi do kontrolera SATA:
- M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,, - M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 ,, - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 ,, - M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 ,, - M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode,, Please refer to the manual for M.2 SSD heatsink restrictions., supports 22110/2280 devices, supports 22110/2280/2260 devices, supports 2280/2260 devices
Uwagi do karty graficznej:
Graphics specifications may vary depending on the CPU installed, Support HDMI 2.1 with FRL port, maximum resolution of 8K 60Hz, Thunderbolt™ 4 ports, supporting DisplayPort 2.1 with UHBR20 over, USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
Uwagi do złącz PCI:
- PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), - PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset), - PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset), PCI_E1 support manual BIOS adjustment to X8+X8/X8+X4+X4
Port równoległy (LPT):
Brak
Ilość złącz pamięci DDR5:
4
Maksymalna ilość portów USB 4.0:
2
Uwagi do WiFi / BT:
6GHz band support may depend on every country's regulations and Wi-Fi 7 (60072), Intel® Killer™ BE1750x Wi-Fi 7, Supports 802.11 a/ b/ g/ n/ ac/ ax/ be, Supports Bluetooth® 5.4**, MLO, 4KQAM, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps, The Bluetooth version may be updated, please refer to the Wi-Fi chipset, The Wireless module is pre-installed in the M.2 (Key-E) slot, vendor's website for details. Bluetooth 5.4 will be ready in (10788), will be ready in Windows 11 version 24H2., Windows 11 version 24H2.
